CM/D Series Compressor For Oxygen Concentrator
As one of the compressor for oxygen concentrator manufacturers, suppliers, and exporters of mechanical products, We offer compressor for oxygen concentrator and many other products.
Please get in touch with us for details.
Mail:sales@compressor-for-oxygen-concentrator.com
Manufacturer supplier exporter of compressor for oxygen concentrator.
CM/D Series Compressor For Oxygen Concentrator
Compressor for oxygen concentrator is a key components in producing concentrated oxygen for medical and industrial use. Oxygen concentrators are used to extract oxygen from the surrounding air and concentrate it for use by patients with respiratory diseases or industrial applications requiring high-purity oxygen.
The compressor in an oxygen concentrator operates by compressing air from the surrounding environment and then filtering and purifying the air to produce high-purity oxygen. Two main types of compressors are used in oxygen concentrators: piston compressors and diaphragm compressors.
CM/D Series Compressor For Oxygen Concentrator Parameters:
Fixed Speed Series
|
Model |
Work pressure |
FAD |
Power |
Air Supply temperature |
Noise |
Weight |
Pipe diameters of cooling water inlet and outlet |
Cooling fan Power |
Dimension |
Air outlet |
|
|
Water entering32℃ |
L×W×H |
||||||||||
|
MPa |
M³/min |
cfm |
kW |
℃ |
dB(A) |
kg |
T/h |
mm |
|||
|
CM45D |
0.12～0.25 |
13.80 |
487 |
45 |
≤45 |
70 |
1720 |
1 1/2ʺ |
12 |
2200×1350×1530 |
DN65 |
|
CM55D |
0.25～0.40 |
13.60 |
480 |
55 |
1750 |
18 |
|||||
|
CM75D |
0.25~ 0. 40 |
20.1 |
710 |
75 |
72 |
2300 |
2 1/2″ |
20 |
|||
|
CM132D |
0.12～0.25 |
43.00 |
1518 |
132 |
78 |
4380 |
3ʺ |
30 |
3100×1700×2090 |
DN125 |
|
|
CM160D |
0.25～0.40 |
42.88 |
1514 |
160 |
4500 |
35 |
|||||
VSD Series
|
Model |
Work pressure |
FAD |
Power |
Air Supply temperature |
Noise |
Weight |
Pipe diameters of Cooling water inlet and outlet |
Cooling fan Power |
Dimension |
Air outlet |
|
|
Water entering 32℃ |
L×W×H |
||||||||||
|
MPa |
M³/min |
cfm |
kW |
℃ |
dB(A) |
kg |
T/h |
mm |
|||
|
CM45DV |
0.12~0.25 |
5.50~13.80 |
194-487 |
45 |
≤45 |
70 |
1720 |
1 1/2ʺ |
12 |
2200×1350×1530 |
DN65 |
|
CM55DV |
0.25~0.40 |
5.40~13.60 |
191-480 |
55 |
1750 |
18 |
|||||
|
CM75DV |
0.25~0.40 |
8.04~20.1 |
282-710 |
75 |
72 |
2300 |
2 1/2″ |
20 |
|||
|
CM132DV |
0.12~0.25 |
17.20~43.00 |
607-1518 |
132 |
78 |
4380 |
3ʺ |
30 |
3100×1700×2090 |
DN125 |
|
|
CM160DV |
0.25~0.40 |
17.10~42.88 |
604-1514 |
160 |
4500 |
35 |
|||||
CM/D Series Compressor For Oxygen Concentrator Feature:
Energy Saving: Energy saving more than 15% compared with dry oil-free compressors.
Environmental protection: do not use any lubricating oil to avoid environmental pollution.
Reliability: No oil is guaranteed.
We are one of the best food compressor suppliers. We have exported our products to clients around the world and earned a good reputation because of our superior product quality and after-sales service. We warmly welcome customers both at home and abroad to contact us to negotiate business, exchange information, and cooperate with us!
Compressor For Oxygen Concentrator Application:
